Flat roof recovery board – Part I

Flat roofing recovery board, also known as insulation board or cover board, is a crucial component used in the construction and installation of flat roofs. It provides thermal insulation, strength, and a stable surface for the roofing system. The manufacturing process for flat roofing recovery board involves several steps, including the selection of subcomponent materials, production, and quality control.

flat roofing recovery board

The following this below describes the characteristics in the manufacturing installation process of polyisocyanurate and other types of recovery board at flat roof top installations:

  1. Subcomponent Materials:
    • Polyisocyanurate (PIR) Foam: PIR foam is a common material used in recovery board manufacturing due to its excellent insulation properties, high compressive strength, and fire resistance. It is typically produced by mixing polyol and isocyanate chemicals.
    • Facers: Recovery boards often feature facers on both sides, which are thin sheets laminated to the foam core. These facers can be made of various materials, such as fiberglass-reinforced cellulosic mat, fiberglass-reinforced polyester, or coated glass fiber mat. The facers provide additional strength, protect the foam core, and act as a bonding surface for the roofing system.

2. Production Process:

    • Foam Mixing: The PIR foam production begins by accurately metering and blending the polyol and isocyanate chemicals in a mixing chamber. This mixture is then poured onto a moving conveyor.
    • Foam Expansion: As the mixture moves along the conveyor, it enters a foaming chamber where it undergoes controlled expansion due to the reaction between the polyol and isocyanate. This process forms a rigid foam with closed cells, providing insulation properties.
    • Facer Application: After the foam expansion, the facers are applied to both sides of the foam core. This can be achieved through a continuous lamination process where the facer materials are fed from rolls and bonded to the foam core using heat and pressure.
    • Trimming and Cutting: Once the facers are bonded, the recovery board is trimmed to the desired dimensions and cut into manageable panels or sheets.

3. Quality Control:

    • Thickness and Dimensional Control: Recovery boards undergo rigorous quality control measures to ensure consistent thickness and dimensional accuracy. This involves measuring the thickness of the foam core and facers at various points and comparing them against specified tolerances.
    • Compression Strength Testing: Flat roofing recovery boards need to possess sufficient compressive strength to withstand the loads imposed by the roofing system and foot traffic. Samples are subjected to compression tests to verify that they meet the required strength standards.

4.Usage and Installation Requirements:

    • Application: Flat roofing recovery boards are primarily used in the construction or refurbishment of flat or low-slope roofs. They are installed on top of the roof deck and beneath the waterproofing or roofing membrane.
    • Insulation and Stability: Recovery boards provide thermal insulation, helping to reduce heat loss or gain through the roof. They also offer stability to the roof, creating a smooth and solid surface for the installation of subsequent layers.
    • Compatibility: It is important to select recovery boards that are compatible with the roofing system being installed. This includes considering factors such as fire resistance, moisture resistance, and compatibility with adhesives and fasteners.
    • Installation Methods: Recovery boards are typically mechanically fastened or adhered to the roof deck using appropriate adhesives.  Proper installation techniques and manufacturer guidelines should be followed to ensure a secure and effective installation.

Flat roofing recovery boards play a vital role in enhancing the performance and longevity of flat roofs. By providing insulation, strength, and stability, they contribute to the overall efficiency and durability of the roofing system.

The upkeep, maintenance, and general care of flat and mansard roof systems should be driven by an understanding and passion for historical methodologies, waterproofing principles, engineering and building science. Washington DC, a city built with both vintage charm and contemporary modernities, residential and commercial buildings of substantial value.

The roofs of these buildings are their defensive shield from the harsh elements of nature. To our clients, as well as all readers of this article and our blog, we emphasize the importance of quality construction and active building maintenance.  Our website includes informative resources you can use to understand and learn about best practices on preservation of your building.  If you are in need of further guidance on the roof and its associated systems for your Washington DC property, we are here to assist, where we can. Simply contact us or complete the webform below and drop us a line and we’ll respond if we can help.
